400D平紋
| 芳綸纖維編織布系列 Aramid(Kevlar®) Fiber Fabrics | ||||||||
型號 Part No. | 纖維規格 Fiber Spec. | 經緯密度 Fiber Count(10mm) | 編織方法 Weave | 質量 Weight(g/㎡) | 厚度 Thickness﹙mm﹚ | 幅寬 Width ﹙mm﹚ | ||
經向 Warp | 緯向 Weft | 經向 Warp | 緯向 Weft | |||||
KP0400082 | Kevlar400 | Kevlar400 | 9.5 | 9.5 | 平紋 (Plain) | 82 | 0.08 | 100-1500 |
KT0400082 | Kevlar400 | Kevlar400 | 9.5 | 9.5 | 斜紋2/2 (Twill) | 82 | 0.08 | 100-1500 |
KP1000155 | Kevlar1000 | Kevlar1000 | 7 | 7 | 平紋 (Plain) | 155 | 0.24 | 100-1500 |
KT1000155 | Kevlar1000 | Kevlar1000 | 7 | 7 | 斜紋2/2 (Twill) | 155 | 0.24 | 100-1500 |
KP1000180 | Kevlar1000 | Kevlar1000 | 8 | 8 | 平紋 (Plain) | 180 | 0.25 | 100-1500 |
KT1000180 | Kevlar1000 | Kevlar1000 | 8 | 8 | 斜紋2/2 (Twill) | 180 | 0.25 | 100-1500 |
KP1000200 | Kevlar1000 | Kevlar1000 | 9 | 9 | 平紋 (Plain) | 200 | 0.26 | 100-1500 |
KT1000200 | Kevlar1000 | Kevlar1000 | 9 | 9 | 斜紋2/2 (Twill) | 200 | 0.26 | 100-1500 |
KP1000220 | Kevlar1000 | Kevlar1000 | 10 | 10 | 平紋 (Plain) | 220 | 0.28 | 100-1500 |
KT1000220 | Kevlar1000 | Kevlar1000 | 10 | 10 | 斜紋2/2 (Twill) | 220 | 0.28 | 100-1500 |
KP1500170 | Kevlar1500 | Kevlar1500 | 5 | 5 | 平紋 (Plain) | 170 | 0.22 | 100-1500 |
KT1500170 | Kevlar1500 | Kevlar1500 | 5 | 5 | 斜紋2/2 (Twill) | 170 | 0.22 | 100-1500 |
KP1500185 | Kevlar1500 | Kevlar1500 | 5.5 | 5.5 | 平紋 (Plain) | 185 | 0.24 | 100-1500 |
KT1500185 | Kevlar1500 | Kevlar1500 | 5.5 | 5.5 | 斜紋2/2 (Twill) | 185 | 0.24 | 100-1500 |
KP1500205 | Kevlar1500 | Kevlar1500 | 6 | 6 | 平紋 (Plain) | 205 | 0.26 | 100-1500 |
KT1500205 | Kevlar1500 | Kevlar1500 | 6 | 6 | 斜紋2/2 (Twill) | 205 | 0.26 | 100-1500 |
KP1500220 | Kevlar1500 | Kevlar1500 | 6.5 | 6.5 | 平紋 (Plain) | 220 | 0.28 | 100-1500 |
KT1500220 | Kevlar1500 | Kevlar1500 | 6.5 | 6.5 | 斜紋2/2 (Twill) | 220 | 0.28 | 100-1500 |
KP1500240 | Kevlar1500 | Kevlar1500 | 7 | 7 | 平紋 (Plain) | 240 | 0.30 | 100-1500 |
KT1500240 | Kevlar1500 | Kevlar1500 | 7 | 7 | 斜紋2/2 (Twill) | 240 | 0.30 | 100-1500 |
KP3000440 | Kevlar3000 | Kevlar3000 | 6.7 | 6.7 | 平紋 (Plain) | 440 | 0.42 | 100-1500 |
KT3000440 | Kevlar3000 | Kevlar3000 | 6.7 | 6.7 | 斜紋2/2 (Twill) | 440 | 0.42 | 100-1500 |
